ZEB-REVO
Introducing the GeoSLAM ZEB-REVO – our latest lightweight revolving laser-scanner. Handheld, pole-mounted, or attached onto your chosen mobile platform such as a vehicle or UAV and pass through your target survey environment to record more than 40,000 measurement points/second.

Features

Ultra Mobile

Weighing only 3.5kg, the handheld ZEB-REVO can be used to quickly scan mullevel environments.

Rugged

With an IP64 rang, the ZEB-REVO can withstand hazardous and harsh environments.

Simple to Use

No need for GPS or control, the one button on/off operation reduces training requirements.

Fast

Complete surveys in minutes, much faster than tradtional surveys or static terrestrial laser scanning.

How It Works

SCAN

Scanning is made simple with the ZEB-REVO, the revolutionary new handheld laser scanner from GeoSLAM. The 100Hz scanner and 360° field of view allows for fast, accurate and high quality data capture.

REGISTER

Automatic SLAM (Simultaneous Localisation And Mapping) cloud-to-cloud registration using either GeoSLAM Desktop processing or GeoSLAM Cloud pay-as-you-go processing.

POINT CLOUD

Resulting 3D point cloud produced in .laz format, as well as trajectory condition files. Extracted .las file compatible with all major industry standard post processing software.

Applications

The ZEB-REVO builds upon the success of its predecessor, the award-winning ZEB1, with a faster scanner,even simpler operation and greater versatility.

At its core is GeoSLAMs industry-leading Simultaneous Localisation And Mapping (SLAM) algorithm,which facilitates rapid mobile mapping of enclosed environments, without the need for GPS.

This versatility renders the ZEB-REVO suitable for a large variety of applications that would otherwise prove difficult or  time consuming using traditional survey techniques.
